Zimmer 21' Gaff Sloop

Product Description
$75.00
Maximum quantity available reached.

Centerboard sloop with inside ballast and two settee berths for coastal cruising.

Designed by Nelson Zimmer

LOA - 21' 1 1/2"
LWL - 16'
Beam - 7' 2"
Draft (cb up) - 2'
(cb down) - 4' 3"
Displ. - 3,110 lbs.
Sail Area - 261 sq. ft.
Construction: Carvel planked over sawn frames
Alternative construction: Strip
Lofting is required
Skill level: Intermediate to Advanced
Plans include 5 sheets.

Sku: 400-044
