Alden 30' Malabar Jr

Product Description
$150.00
Maximum quantity available reached.

Carvel-planked, outside ballasted cruiser with choice of three or four berths.

Designed by John Alden

LOA - 30' 0"
LWL - 23' 3"
Beam - 9' 8"
Draft - 5' 0"
Displ. - 12, 683 lbs.
Sail Area : Sloop - 528 sq. ft. Yawl - 579 sq. ft.
Construction: Carvel planked over steamed frames
Alternative construction: Cold-molded or strip
Lofting is required
Skill level: Advanced
Plans include 7 sheets, plus 7 pages of additional notes from the designer.

More info: click MATERIALS LIST.

Sku: 400-004
